… and the Car HMI Europe Award 2021 in the category “Most Innovative Application of Machine Learning & AI in Automotive HMI + UX” goes to:
… Candera’s “Smart AI-based graphics Importer”!
The Smart Importer is the highlight feature of Candera’s latest CGI Studio 3.10, which had just been presentedat the Car HMI Europe for the first time. Candera’s Smart Importer enables all users (including those without programming skills) to automatically generate full functioning HMIs using their designs from any graphics software – opening the door to faster, more efficient HMI creation: https://youtu.be/7RaKP-Pyb7c
The Car HMI Europe Award exclusively honours exceptional projects in the automotive industry. It celebrates outstanding solutions, innovations and unique development processes in automotive user experience, UIs and HMIs. Luxoft, Mercedes-Benz and Candera are the winners of the 2021 edition.
“The winners have set a new standard for innovation and creative technology within the automotive industry,” said Swetlana Torosyan, Producer of the Car HMI Europe 2021. “This award is a testament to the skill, ingenuity, and vision of the creators. Being able to present the future in real time is an absolute privilege.”
Among all applications, the best 6 projects were nominated by an internal jury of experts. The criteria for the nomination are:
How easy is the project to realize and to maintain?
How innovative or unique is the approach?
What is achieved through the implementation?
Is the function ready to use?
Cost efficiency – what is the balance of development costs and savings?
At the Award Ceremony during the Car HMI Europe event, all nominees presented their solutions in a short video. Via live voting, the Car HMI Europe community voted for their leaders and projects that show outstanding efforts to bring user interaction and UX to the next level. Congratulations to Luxoft, Mercedes-Benz and Candera for winning the CAR HMI Europe Award 2021!”
Candera wins with Candera’s AI assisted Smart Importer the category ‘Most Innovative Application of Machine Learning & AI in Automotive HMI + UX’. Runner up is Mercedes-Benz with their “MBUX Zero Layer”.
“The automotive industry is going through exciting changes right now, and the winners of this award is clearly at the frontline of their game. We are already looking forward to next year’s event and awards to see what they can come up with next”, concludes Swetlana Torosyan at the Car HMI Europe Award Ceremony.
The “Smart Importer” now also permits direct import from PSD, Sketch or Axure RP. It helps designers save precious time and costs.
About Candera
Candera, is a leading HMI tool provider and development partner for worldwide automotive and industrial customers. It supports its customers with the CGI Studio tool environment as well as provision of software services mainly in the areas of HMI development and embedded software. Candera GmbH in Linz, Austria and Candera America Inc. are part of KAGA FEI Co., Ltd., situated in Yokohama / Japan.
Candera GmbH is delighted to announce to have been nominated with their “Smart Importer” for the Car HMI Europe Award 2021 in the category “Most Innovative Application of Machine Learning & AI in Automotive HMI + UX”.
The “Smart AI-based graphics Importer” is the highlight feature of CGI Studio 3.10, which will be presented at the Car HMI Europe for the first time. Candera’s Smart Importer enables all users (including those without programming skills) to automatically generate full functioning HMIs using their designs from any graphics software – opening the door to faster, more efficient HMI creation.
Taking place from June 27-29 in Berlin, Germany, the well-established international knowledge exchange platform brings together all stakeholders playing an active role in the technical and design field for automotive HMI and UX development.
The Candera team is glad to be back in person after all the remote events and will proudly present for the first time Candera’s latest CGI Studio version 3.10. In the spotlight is the now established “Smart AI-based graphics Importer”, which automatically transforms graphics into fully functional HMIs. The “Smart Importer” now also permits direct import from PSD, Sketch or Axure RP.
More highlights of CGI Studio 3.10 include the new Japanese user interface in addition to English, enhanced samples and tutorials for easy onboarding, and improved “Candera LINK” remote rendering.
All of which will help designers to save precious time and costs.
The Candera team is looking forward to meeting you at the Car HMI Europe from June 27-29:
TITANIC Chaussee Berlin Chausseestraße 30, 10115 Berlin, Germany
About Candera
Candera, is a leading HMI tool provider and development partner for worldwide automotive and industrial customers. It supports its customers with the CGI Studio tool environment as well as provision of software services mainly in the areas of HMI development and embedded software. Candera GmbH in Linz, Austria and Candera America Inc. are part of KAGA FEI Co., Ltd., situated in Yokohama / Japan.
Human Machine Interface (HMI) technology to be integrated in TFT Instrument Clusters for Automotive applications
Varroc Engineering Limited (Varroc), a global Tier-1 auto component manufacturer, has signed a Memorandum of Understanding (MoU) with Candera GmbH, a leading HMI tool provider and development partner for worldwide automotive and industrial customers, for a strategic association to share the Human Machine Interface (HMI) technology for Varroc’s TFT Instrument Cluster.
According to the MoU, Varroc will develop hardware and the base software of the product, while Candera will provide software solution for HMI. This MoU will enable both the companies to respond to the emerging TFT Instrument Cluster opportunities in India & global market for Automotive applications with shorter lead times and cost optimized solutions.
Candera, is a leading HMI tool provider and development partner for worldwide automotive and industrial customers. It supports its customers with CGI Studio, a scalable and hardware independent HMI design software. The special USP of CGI Studio are its user-friendly interface and the high-performance representation of 2D / 3D display elements and animations. Furthermore, it comes with ready-to-use HMI controls, an AI assisted Smart Importer and integrated state machines.
Speaking on the partnership, Arjun Jain, Whole-time Director and the President – Electrical Business Unit at Varroc, said “We are glad to partner with Candera for the HMI technology. With our complementary capabilities, we aim to create business synergies to enhance our existing product as per customer requirements. The partnership will also empower our TFT Instrument Clusters as a comprehensive product and strengthen its reliability in the market.”
Also Reinhard Füricht, CEO of Candera appreciates the cooperation with Varroc. “We have been collaborating with Varroc already successfully the past years”, says Reinhard. “This MoU now takes our partnership to the next level and we’re looking forward to support our mutual, worldwide customers to be successful in their business by creating powerful HMI solutions together with Varroc’s TFT clusters.”
About Varroc Engineering Ltd.
Varroc Engineering Ltd is a global tier-1 automotive component group, incorporated in 1988. The group designs, manufactures and supplies exterior lighting systems, plastic and polymer components, electricals-electronics components, and precision metallic components to passenger cars, commercial vehicles, two-wheelers, three-wheelers, and off-highway vehicle OEMs directly worldwide. The group revenue was close to ₹ 11,200 crores (USD 1.5 Billion) in FY20. The group employs more than 14,300+ employees, has 44 operating manufacturing facilities across five continents, and has 161 patents as of December 31, 2020. Varroc Engineering Limited’s shares are listed on the National Stock Exchange of India Limited (VARROC) and the BSE Limited (541578).
About Candera
Candera, is a leading HMI tool provider and development partner for worldwide automotive and industrial customers. It supports its customers with the CGI Studio tool environment as well as provision of software services mainly in the areas of HMI development and embedded software. Candera GmbH in Linz, Austria and Candera America Inc. are part of KAGA FEI Co., Ltd., situated in Yokohama / Japan.
February 15, 2021 – Linz/ Austria – Candera is excited to announce that it has been accredited as first certified partner within Infineon’s HMI Tool Certification Program. Infineon has designed this special evaluation program in order to ensure the best customer satisfaction and experience when using HMI software with the TRAVEO™ II Graphic Controllers.
Picture 1 Candera to be certified as first HMI tool partner for Infineon’s Traveo II-C
Since many years Candera, a leading HMI-tool provider, has been cooperating with Cypress, an Infineon Technologies AG (FSE: IFX / QTCQX: IFNNY) company in order to create the perfect HMI solutions for the TRAVEO-series, starting with the reference board Amber S6J3200 up to TRAVEO II Graphic MCUs (CYT4DNxxx). So, there was no hesitation for Candera in participating at Infineon’s latest HMI Tool Certification Program and to successfully implement the defined requirements: setting up a full virtual animated dashboard as well as a warped dual Head up Display using CGI Studio and the TVII-C CPU boards, while leveraging all the HW features that the GPU offers.
A special challenge within the virtual dashboard was the implementation of the animated media coverflow between the 2 gauges. Since all media graphics of the dashboard were only available in 2D, the whole coverflow has been realized in 2.5D, allowing a similar depth perception than 3D. For this 2.5D implementation Candera had to provide the possibility to dynamically change the transformation matrix of all objects.
Furthermore, cluster and HuD were based on 3 different layer types: IBO (Image-based operation) for traditional frame buffer drawing, LBO (Line-based operation) Increased BLIT engine performance and reduced memory and OTF (On-the-fly mode) to reduce VRAM memory consumption. All of them implemented successfully by the Candera team.
The head-up display had to be accomplished in two different modes, warping off (for projection on planar surfaces) and warping on (for projection onto the windscreen). Similar like the transformation matrix of the 2.5D use case, the distortion for the warping has been created by using the display warping feature in order to simulate the bending of the windshield.
Within this HuD use case, CGI Studio also supports the text rendering by Traveo II draw engine.
Picture 2: Full virtual instrument cluster and warped dual Head-up display created with Candera CGI Studio on TRAVEO II
Candera is very excited to be the first certified HMI tool partner for Infineon’s TRAVEO™ II Graphics Controller. “Infineon’s TRAVEO series has always been the perfect match for our HMI design tool CGI Studio, says Reinhard Füricht, general manager of Candera. “As certified tool partner we are more than happy enabling our mutual customers to create powerful HMI solutions with a special focus on low-memory footprint.”
Also, Sven Natus, Senior Director of the Automotive Microcontroller Business Unit at Infineon showed his appreciation “The implementation of compelling and cost competitive HMI solutions has ever been a challenge. We have been partnering with Candera for many years on the TRAVEO series. This certification now takes our partnership to the next level and enables customers to quickly and easily implement their HMI design while getting the best performance out of the system.”
About Candera
Candera, is a leading HMI tool provider and development partner for worldwide automotive and industrial customers. Candera supports its customers with the CGI Studio tool environment as well as provision of software services mainly in the areas of HMI development and embedded software. Candera GmbH in Linz, Austria and Candera America Inc. are part of KAGA FEI Co., Ltd. , situated in Yokohama / Japan.
About Infineon
Infineon Technologies AG is a world leader in semiconductor solutions that make life easier, safer and greener. Microelectronics from Infineon are the key to a better future. In the 2020 fiscal year (ending 30 September), Infineon reported revenue of more than €8.5 billion with a workforce of some 46,700 people worldwide. Following the acquisition of the US company Cypress Semiconductor Corporation in April 2020, Infineon is now a global top 10 semiconductor company.
Infineon is listed on the Frankfurt Stock Exchange (ticker symbol: IFX) and in the USA on the over-the-counter market OTCQX International Premier (ticker symbol: IFNNY). Further information is available at www.infineon.com.
Linz/Vienna/Munich – 16/02/2021 – Candera, a leading provider of HMI design tools, next system, a renowned expert of customized haptic hardware solutions and DATA MODUL, a leading partner for display technologies have been cooperating on the development of an innovative HMI solution, supporting intuitive touch feedback technology. Featuring different use cases in application fields like industry, nautics, medicine and many more, the solution also includes a haptic pin pad, that supports person with visual impairment. This innovative haptic HMI will be presented at (digital) Embedded World, from 1-5 March, 2021.
Candera’s, next system’s and DATA MODUL’s haptic Multi-Scene HMI solution supports intuitive touch gestures for multiple use cases
Following several studies about the hierarchy of human senses, touch is often named as one of the most important ones after visual and auditory impulses. Therefore, it is not surprising, that not only our physical but also the artificial world can be enriched from an enhanced input of touch stimuli. The incorporation of haptics and touch feedback technology into displays and touch screens is no future trend, it has already found its way into many application fields like automotive, industry or medicine. Adding these intuitive operating concepts to static devices transforms standard UI solutions into immersive and living HMI experiences.
Based on these insights, Candera GmbH, a leading HMI tool provider, next system, a renowned expert in haptics, displays, computers and motors together with DATA MODUL, a leading partner for display technologies have merged their expertise in order to create a modern Multi-Scene-HMI solution with intuitive and haptic touchscreen support. The result is a highly perceptive User Interface that combines the best out of 2 worlds: perfect HMI design and enhanced haptic technologies.
Intuitive touch feedback of displays and devices is no longer a privilege of the automotive industry. It has already found its way into multiple application fields like industry, medicine, entertainment and many more. This is why Candera, next system and DATA MODUL have highlighted several different use cases across various industries, among them a 2D/3D excavator UI, a nautic sea map, an ultrasonic control unit, a dynamic cashpoint pin pad and more. Indeed, this pin pad supports persons with visual impairment, who can successfully interact with the UI purely based on the haptic and auditory feedback they receive from the device.
Intuitive Cash Point Pin Pad with haptic and auditory feedback to support persons with visual impairment
All of these use cases have been created with Candera’s HMI design tool CGI Studio, a highly intuitive and user friendly GUI design software. Thanks to Candera’s powerful render engine, the scenes not only feature pin sharp graphics but also 3D elements and animations. CGI Studio’s automated workflows, like the ready-to use controls, integrated state machines but especially the Smart Photoshop Importer have helped to rapidly turn the flood of images and animations linked to these multiple scenes into living HMIs – and this within only a few weeks instead of months.
next systems innovative hardware technologies were the perfect match to Candera’s HMI solutions. As a pioneer in haptic touch solutions, next systems target was to create a state-of-the-art haptic touch demonstrator for several applications. The device includes two 10,1“ touch screens with haptic feedback support based on electrostatic- and piezo-technology. Both screens include force-sense (Force measurement for targeted and safe triggering on the user interface) in order to ensure high quality user experience. The integrated haptic touch technology can be tailormade applied to almost all touch sensitive applications.
“With Candera, as a specialist in HMI UI design, next system found the perfect partner to realize this very versatile project in a very short time frame,” says Michael Nussbaumer, Product Manager for Display & Haptic Solutions at next system “The scenes, screens and functions where quickly created and integrated on the target hardware. The efficient cooperation enabled a quick and cost-efficient execution of the overall project.”
DATA MODUL provided the custom refined cover glass including the latest version of their SITO projective capacitive touch unit. Additionally, the display expert was taking care of the fine tuning mostly for touch adjustments and TFT driving. This set-up of all included components ensured the perfect combination and integration of Candera´s HMI and next system´s haptic touch solution.
The new haptic HMI solution will be presented the first time at Embedded World 2021 at the virtual booth of Candera as well as during Candera’s speaker presentation at the exhibitor forum on March 2, 2021 at 11.25 AM, in which David Aberl, Head of Product Management will talk about the Next Generation of HMI development tools.
About Candera
Candera, is a leading HMI tool provider and development partner for worldwide automotive and industrial customers. It supports its customers with the CGI Studio tool environment as well as provision of software services mainly in the areas of HMI development and embedded software. Candera GmbH in Linz, Austria and Candera America Inc. are part of KAGA FEI Co., Ltd. , situated in Tokyo / Japan.
About next system
next system is an Austrian owner-managed company and leading provider of solutions and products in the areas of Motors, Embedded Computers, Displays & Touch, Medical Solutions and Haptic Touch Solutions. Long-standing and selected partnerships with established manufacturers, deep technical know-how and a strong understanding of our customers are the foundations of our success.
About DATA MODUL
DATA MODUL AG is one of the world’s leading specialist providers of display, touch, embedded, monitor and panel PC solutions. Since it was established in 1972, it has consistently pursued the objective of providing its customers with state-of-the-art, tailor-made and individually customized complete solutions for display technologies. The extensive distribution portfolio of displays, touchscreens and embedded solutions and the increasingly innovative in-house developments complete the unique modular product portfolio.
Linz/Austria – Seoul/ South Korea, 9/11/2020 – LG Electronics Inc. is excited to announce the development of an innovative AR solution supporting various displays such as head-up display (HUD) and center information display (CID) for automotive and in-vehicle use. This modern AR solution displays situational key information like ADAS alerts, navigational hints, points of interest (POIs), or pedestrian detection directly onto the road by augmenting the real world with computer-generated visual graphics. It also supports fully customizable modeling of AR user interfaces without complicated coding to enhance the user experience (UX). This is the result of the collaboration with Candera GmbH, one of the leading HMI tool providers for automotive and industrial customers worldwide.
LG Conniro™ AR provides an intuitive user experience by augmenting the real world with computer-generated visual information.
LG’s AR solution supports intuitive AR scenes to reduce driver distraction
With the growing number of vehicles on the road the need for safety and reduced driver distraction is one of the most important factors driving the integration of AR solutions for HUDs and CIDs in the automotive market. Furthermore, whilst in the past head-up displays often were an optional or standard feature for premium cars only, in the near future they will also find their way into economy and standard vehicles. OEMs worldwide are currently exploring the possibilities and use cases of this new technology.
Based on this awareness LG Electronics Inc. situated in Seoul/ South Korea has been boosting its efforts to develop a modern AR solution that works with various in-vehicle displays such as HUD and AVN/CID. Unlike traditional HUDs displaying static information AR Head-up displays go one step further by blending in key information directly onto the lane and into the driver’s field of view. This of course requires the integration of a huge amount of vehicle sensor data, enabling a real-time projection of information, warnings and alerts. To implement these complex requirements LG Electronics has developed a powerful AR engine in order to be able to merge the real world with the digital content. LG AR engine is built upon the advanced sensor fusion framework that merges information observed by in-vehicle sensors in real time and predicts the future state of all interest objects around the car. This sophisticated signal processing framework ensures the stabilization of AR contents against vehicle dynamic motions and achieves reduced time delays, caused by system latency, between AR contents and the real world. LG’s AR engine is well optimized in terms of computational complexity, such that it achieves high frame rate in low performance system-on-chip (SoC) environments. In addition, it is also applicable to mobile devices like Android phone by using built-in mobile sensors as input to the AR engine.
LG’s AR solution features navigational hints, safety guides and an advanced POI Service
Combined with LG’s enhanced visualization technologies the result was a modern AR solution supporting intuitive AR scenes like navigational hints (route carpets, directional arrows, goal pins, POI highlights), ADAS alerts (active cruise control, lane departure warning, forward collision warning, pedestrian detection), and many more. Currently, LG’s AR solution is ready for the market and is in the process of mass production with a number of OEMs. “We believe that our technical readiness will provide better values to our customers, and mass production experience of various OEMs will further expand our business in the market” said Sukjin Chang, vice president of Smart Mobility Lab. in LG Electronics.
Candera CGI Studio makes LG’s AR solution fully customizable
To make the AR solution fully customizable for different OEM UX requirements LG was looking for an experienced HMI expert and development partner. That’s when Candera came into play. The Austrian HMI tool provider was enhancing the existing HUD with the powerful Candera render engine, to minimize latency and enhance clarity of the indicated information. “Especially when it comes to ADAS alerts or safety warnings, it is important that the information is displayed in real-time with zero delay” explains Roberto Hofer, technical sales manager of Candera. ”Incorporating further performance and latency optimizations into our render engine, we can ensure an in-time visualization of warnings as well as a pinpoint accuracy of visualized objects even at high speeds.”
AR simulator allows convenient development with recorded or simulated traces without permanent real-track necessity
Another common OEM requirement is an easy and fully customizable HUD. This was realized with Candera’s HMI design tool CGI Studio that has been developed on a user-friendly no coding approach. Indeed, CGI Studio’s ready-to use controls and automated workflows will support OEMs to customize the automotive AR solution to their personals needs without programming a single line of code.
For more information about the new AR solution please contact:
Candera, is a leading HMI tool provider and development partner for worldwide automotive and industrial customers. It supports its customers with the CGI Studio tool environment as well as provision of software services mainly in the areas of HMI development and embedded software. Candera GmbH in Linz, Austria and Candera America Inc. are part of KAGA FEI Co., Ltd. , situated in Tokyo / Japan.
